The Global and Local Matrixes within Cinema 4D can be both lifesavers and death eaters at the same time. A recent project forced me to learn more about them, and I thought I’d pass along some of that knowledge to you.

The first thing I discovered was that you can can convert a Normal Vector into a matrix by use of the Vector2Matrix xpresso node found within the xpresso nodelist under New Node –> Xpresso –> Calculate. Robert Leger has a fantastic guide on the node, which you can find here.

But a problem quickly arose: when I set this new matrix as the Global Matrix of an object, the object locked itself to the origin of my scene (position 0,0,0).

After spending many hours consulting the C4D Python help guide and experimenting on my own, I figured out both the cause of the problem and a method of fixing it.

In Cinema 4D, a matrix is composed of three vectors named V1, V2, and V3. When used as a Global or Local Matrix, these three vectors contain the rotation and scale values associated with the object. In addition, every Global and Local Matrix contains a fourth Vector called ‘Offset’ (abbreviated as ‘off’); this Vector contains the position values of the object.

Therefore, if one converts a normal vector to a matrix, and wishes to use said matrix as the global matrix, the Offset Vector needs to be changed.

To accomplish this task, I created the Matrix Splice xpresso node.

The node is very easy to use: first, feed your current matrix to the ‘Matrix’ input of the node, then feed the Global Position value you’d like to splice into the matrix into the ‘Position’ input. Your new and improved Matrix can be accessed from the “New Matrix” output tab.

Download link:
Matrix Splice Python Node

To install on OS X, drop the XMA file into the following location: User  –> Library –> Preferences –> MAXON –> Cinema 4D [Your Version] –> Library –> xgroup.

Once it’s placed in that folder, you can access the node within your Xpresso Editor window by clicking on File (the ‘File’ button in your Xpresso window, not the ‘File” button located at the top left of your monitor) –> Load X-group.

If you have any trouble with it, let me know.

—
Luke

It’s a hot topic on film blogs everywhere: 48 frames per second. Hollywood’s current standard of 24 frames per second dates back to the 1920s and 30s, when engineers were trying to figure out how to encode sound within celluloid film.

In recent months, filmmakers such as Sir Peter Jackson, Mr. James Cameron, and Mr. Douglas Trumbull have been proponents for an increased frame rate of 48fps, which would eliminate strobing, flickering, and other artifacts present in most modern day films.

Many argue that these artifacts are fundamental to the experience of cinema as we know it, and that their elimination would result in the disappearance of the undeniable magic found in film.

However, an argument in either direction cannot be made without experiencing several films in both mediums. And as it stands right now, our sample sizes are a bit lopsided.

Sir Jackson aim to remedy that situation, and has captured his latest film - The Hobbit - at 48fps.

The response to that knowledge has been mixed, to say the least. Some like it, many hate it, half don’t even know what it means, and the only people to have actually seen any Hobbit footage at 48fps are those lucky enough to have attended a special screening at CinemaCon.

I thought it time to assist in the matter, and give the average person a chance to see how the final product might look. So as a personal project, I converted The Hobbit’s teaser trailer into 48fps.

While it doesn’t truly reproduce the effect you’ll see on the big screen in December, it helps to demonstrate how The Hobbit will be different from a normal 24fps film.

“Now we see but a poor reflection as in a mirror; then we shall see face to face.”

Since there aren’t any online services currently available for streaming high frame rate footage, you will need to download the video clip in order to watch it.

Due to the sheer quantity of data stored in each second of 48fps footage, many computers will struggle to play it smoothly. For this reason, I have provided three different download links to choose from:

High Quality – for those with fast computers*.
Medium Quality – for those with average speed computers.
Low Quality – for those with slower computers.

DISCLAIMER: This video is an UNOFFICIAL presentation of the trailer in the 48fps format, and contains occasional visual distortions that are a result of the conversion process. This footage does NOT truly demonstrate how the final version of the film will appear; it merely helps to demonstrate how it will be different from a normal 24fps film.

*The High Quality video is presented as an FLV file, so you’ll need to get the popular VLC Player (free for both Mac & Windows) in order to watch it.

My Nuke script used for the conversion.

Reducing the Strain

What did you do upon hearing that The Hobbit would be presented in 48fps? I jumped for joy, as it would relieve a problem I’d dealt with for the last several years:  eye strain. Anything with a flicker caused me to go cross-eyed: CRT monitors, fluorescent lights, even the strobing seen in a film. The thought of watching a movie without hurting my eyes was exciting to say the least.

But what would it look like? I had experienced a higher frame rate on the small LCD screen of my Canon 7D, but I’d never shot anything serious in that format, nor had I seen any kind of professionally crafted footage at that speed.

This curiosity intensified in December of 2011 when the first teaser trailer for the Hobbit appeared. I kept wondering, “How was this footage going to look at 48? Better? Worse?”

The screenings in late April polarized the media, and left the rest of us to speculate on things not yet seen.

My interest turned to impatience, and I began to explore the possibility of post-converting the trailer into a higher frame rate. Several methods of accomplishing this task presented themselves, each with with their own distinct strenths and weaknesses.

Just as a stereoscopic post-conversion will never truly match up to a film shot natively in the format with two cameras, the techniques that I’ll outline in the following paragraphs will never recreate the effect gained by shooting natively at that frame rate.

As far I know, the following article is the first public repository of information on this topic. If you know of any others, or have any further knowledge related to this concept, please drop me a line – what I have written here just scratches the surface of what it could become.

Without any further ado, let’s get going.

Initial Conversion

Those familiar with post-production are no doubt aware of plug-ins such as Twixtor and Kronos that allow users to turn their regular speed video footage into super slow-motion extravaganzas. Essentially, these programs examine each frame of footage you provide and figure out what happens between each pair of adjoining frames. It can then use this data to create entirely new frames that are placed between the originals.

Kronos examines the original frames (black) before creating new frames (grey). The source frames are then discarded so that flickering doesn’t occur in the new footage.

When used at its default settings, Kronos will take a piece of source footage and reduce it’s speed by 50% - a process that  doubles the amount of frames present, meaning each second of original footage would have it’s 24 original frames converted to 48 new frames.

Now it’s just a simple matter of repurposing the frames’ metadata so that they increase the frame rate of the footage instead of slowing it down.

To best accomplish conversion via Kronos or Twixtor, the user must first separate their original footage into individual shots, then apply this effect onto each of them one at a time, taking time to tweak the plug-in’s settings for optimal quality.

After the shots have been rendered, they can be recombined into a new sequence, re-synched to the original soundtrack and exported into a rudimentary form of 48 fps.

Distortion

While the footage may play back at the correct speed, it may not look anywhere near correct. Software packages such as Kronos usually create some form of distortion on clips that contain significant motion.

This can be seen throughout my post-conversion of the trailer: watch closely as the dwarves toss plates over Bilbo’s table, and also as Bilbo hops the Hobbiton fence in the following shot.

When Kronos attempts to process clips with a significant amount of motion, distortions are usually created.

Kronos provides several tools within the plug-in for dealing with many kinds of distortion. Most of these techniques require some time to execute, and may or may not work within the paramaters of the particular shot you’re working on. Like a difficult color key, trial and error may serve to be the only plan of attack.

Brute Force

Some shots have so much motion between frames that nothing can be done within the plug-in itself to achieve a clean result. It’s at this point that a brute force technique must be implemented to generate new frames. Working by hand is incredibly slow, but it produces high quality results on tough shots.

My technique of choice was the use of SplineWarp nodes in Nuke which allow the user to “warp” between two master frames, thus allowing the creation of additional frames in between.

A SplineWarp node at work. Pink dots represent a point’s position on the first master frame, blue dots represent where those points moved to on the second master frame.

Two trees of SplineWarp nodes; each grey rectangle represents a single new frame.

To convert one second of regular footage, 24 new frames need to be generated. On average, it took me 15 minutes to do one frame. That’s 12 hours to convert just two seconds of footage. Needless to say, this technique is best saved as a last resort.

Saving Time

In situations where you don’t have much time (i.e. always), it may be necessary to cut corners by eliminating time consuming steps. If one was attempting to quickly convert a sizable sequence that didn’t contain notable quantities of fast movement or require a significant amount of brute-force conversion, it might be worth while to run the entire sequence through Kronos or Twixtor in one go instead of separating it into individual shots before conversion.

This can be a bit of a gamble, but if your settings are good you can convert a significant amount of footage right off the bat. You would then have to sort through the resulting render and hand pick sections that need more attention.

Minor distortions could be fixed by painting them out frame by frame. This technique is quite forgiving as each frame is seen for only a fraction of a second, and the eye doesn’t have much time to discern minor changes in sharpness or tonality.

Distortions on the title shot were perfect candidates for cleaning via RotoPaint nodes in Nuke as there was plenty of material in the surrounding frames to clone from.

Converting a multi-shot sequence all at once creates a unique form of distortion whenever the footage cuts from one shot to the next. Essentially, the plug-in will attempt to create two new frames in the space between the two shots, resulting in a highly deformed transition.

When sending a multi-shot sequence through Kronos, “transitional distortions” are automatically created by the program in an attempt to create a smooth transition between each shot.

Considering the quantity of individual cuts present in an average three minute sequence (the trailer contained over 75) a method must be created by the VFX house to automate the process of fixing the transitional distortion; otherwise the time saved by converting the entire sequence at once will be greatly reduced.

I eventually settled on a series of Nuke nodes that replaced the distorted frames with a duplicate of the nearest clean frame. This results in the last clean frame of the previous shot and the first clean frame of the following shot appearing on screen for 1/24th of a second instead of 1/48th. A cheat of sorts, but it does work: our eyes are too distracted by the change in image to notice the longer frames.

My grouping of Nuke nodes used to remove the transitional distortion.

Several Python expressions were written to automate the process, driven by a user-submitted frame value that highlighted the last clean frame before a transition. This value is checked against the current frame of the composition to determine the values for the fades & mixes.

Placing the nodes into a group and saving them as a Nuke ToolSet significantly sped up the process, allowing me to clean a single transition in only 10-15 seconds.

Exporting

When the desired result has been attained and all frames have been rendered, it’s time to re-synch the audio and attain a quality export. Nuke doesn’t have a proper timeline to do the sound synching, and Final Cut 7 doesn’t work well with image sequences (I haven’t used FCX, so I’m not sure of that). Adobe Premiere & Media Encoder CS5.5 don’t work natively with 48fps material (though they do work with 60fps).

After exhausting those options, I settled on performing these tasks in After Effects, which handled the job decently. As there aren’t a whole lot of compression options directly in AE, I opted to export a lossless Quicktime file that I could bring into MPEG Streamclip for the heavy lifting.

I discovered that (as always) it’s very important to test your 48fps exports on different computer systems so that you know whether or not they’ll play smoothly. Highly compressed footage, though smaller in size, can choke up an average computer system. This is why my “Medium Quality” clip is 100 mb larger than the “High Quality” clip.

In Conclusion

If the 48fps format is as successful as it’s proponents believe it will be, then it won’t take long for Hollywood to realize that converting older films into 48fps will generate more income for the studios and provide more jobs for the VFX industry.

Now is the time for companies such as The Foundry and The Pixel Farm to develop new technologies that assist in the process, making it a smoother experience for everyone else down the road.

Sir Jackson: You’ve got my full support on this endeavor, and I can’t wait to see The Hobbit in it’s full glory on the big screen. What a glorious day that shall be.

-
Luke Letellier
